FEATURES:
- Stainless steel exterior & interior
- Stainless steel grease drawer
- Heavy-duty 3/4’’ thick polished steel griddle plate
- 30,000 BTU burners per 12" section with standby pilots
- Independent manual controls for each 12’’ section
- 3/4’’ NPT rear gas connection and regulator
- Stainless steel legs standard
| SPECIFICATIONS | ||
|---|---|---|
| Model | ATMG-24 | |
| Burners and Control Method | 2 Burners, Independent Manual Control | |
| Gas Type | NG & LP | |
| Per BTU B.T.U./h | NG | 30,000 |
| LP | 30,000 | |
| Total BTU (BTU/h) | NG | 60,000 |
| LP | 60,000 | |
| Intake-tube Pressure (in. W.C.) | NG | 4 |
| LP | 10 | |
| Regulator | NG | 4’’ w.c. |
| LP | 10’’ w.c. | |
| Work Area(inch) | 23 9/10 x 19 9/10 | |
| Exterior Dimensions (inch) | 24 x 28 3/5 x 15 1/5 | |
| Net Weight (lbs) | 161 | |
| Gross Weight (lbs) | 195 | |
