FEATURES:
- White exterior & interior
- 20% more efficient than any walk-in series on the market
- Available in nominal sizes from 6’ x 6’ up to 10’ x 12’, all 7’7” high with floor standard (indoor models only)
- Foamed-in-place 4” panels with cam locks
- Top-mount drop-in refrigeration system, with low noise level and R404A refrigerant (overall height is 10’ with condenser installed, recommend ceiling height 11’)
- 3 spring-loaded heavy-duty Kason door hinges standard
- 36” door with diamond tread kick plates and heated frames standard
- Heavy-duty Kason door closer
- Heavy-duty Kason door handle with lock and inside safety release
- Exterior ramp (34 1/2″ x 27 1/2″) standard
- Digital LED light standard
- Reinforced floor standard
- 48” ceiling mount LED standard
- Coolers maintain 35 °F – 38 °F
| SPECIFICATIONS | |
|---|---|
| Model | AWC0608-TF |
| Rated Current (A) | 12 |
| Voltage (V/Hz/Ph) | 208~240/60/1 |
| Breaker | 30 |
| HP | 1.5 |
| Refrigerant | R404A |
| Exterior Dimensions (inch) | 72 x 96 x 117 |
| Condensing Unit Weight (lb) | 216 |
| Evaporator Weight (lb) | 218 |
| Panel Weight (lb) | 1120 |
